0.6m 9W / 1.2m 18W / 1.5m 22W
1. This product has been TUV, CE, RoHS certification approval.
2. Use high quality 2835SMD LEDs.
3. High-grade PC cover with nice light transmittance (>85%).
4. Use the high quality aluminum PCB for LED’s better heat dissipation.
5. 140º beam angle makes the lighting effect better.
6. Ambient temperature: -20℃~40℃, surface temperature: 42℃~45℃.
7. No mercury, lead or other hazardous materials; no radiation, no electromagnetic radiation, no frequency flash, instant startup, no hurting eyes.
Model: SNS-T8Q-60-9W
Power Consumption: 9W
Dimension: φ26 x L590mm
LED Type: 48pcs SMD2835
Luminous Flux: 900-1100lm
LED Color: WW, DW, PW
Color Temperature (K): 3000K, 4000K, 6000K
CRI: Ra>80
Input voltage: 95-265V AC
Work frequency: 50/60Hz
Power Supply: Non-isolated Power Supply
PF: >0.9
Beam Angle: 270°
Housing material: Plastic + Aluminum
PC Cover: Milky white cover
Operating Environment: -20°C to 40°C
Storage Environment: -20°C to 60°C
Theoretical Lifespan: 30000H
Warranty: 3 Years
Model: SNS-T8Q-120-18W
Power Consumption: 18W
Dimension: φ26 x L1198mm
LED Type: 96pcs SMD2835
Luminous Flux: 1800-2000lm
LED Color: WW, DW, PW
Color Temperature: 3000K, 4000K, 6000K
CRI: Ra>80
Input voltage: 95-265V AC
Work frequency: 50/60Hz
Power Supply: Non-isolated Power Supply
PF: >0.9
Beam Angle: 270°
Housing material: Plastic + Aluminum
PC Cover: Milky white cover
Operating Environment: -20°C to 40°C
Storage Environment: -20°C to 60°C
Theoretical Lifespan: 30000H
Warranty: 3 Years
Model: SNS-T8Q-150-22W
Power Consumption: 22W
Dimension: φ26 x L1498mm
LED Type: 120pcs SMD2835
Luminous Flux (lm): 2000-2200lm
LED Color: WW, DW, PW
Color Temperature (K): 3000K, 4000K, 6000K
CRI: Ra>80
Input voltage: 95-265V AC
Work frequency: 50/60Hz
Power Supply: Non-isolated Power Supply
PF: >0.9
Beam Angle: 270°
Housing material: Plastic + Aluminum
PC Cover: Milky white cover
Operating Environment: -20°C to 40°C
Storage Environment: -20°C to 60°C
Theoretical Lifespan: 30000H
Warranty: 3 Years
1. Fish tank, chicken farms, pig farms, Herbs shed, vegetable shed, Bridges, commercial building edges.
2. Outdoor lighting, Refrigerator or freezer show lighting, Cold storage lighting, Other humid environments lighting, etc.
